Frame
BallisTec Carbon front triangle, SmartForm C1 Alloy swingarm, 150mm travel, Ai offset drivetrain, ISCG05, PF30-83, flat mount brake, tapered headtube
-
Fork
Fox Float Factory 36, 150mm, Grip2 Damper, Kashima coating, 15x110, tapered steerer, 44mm offset
-
Rear Shock
Fox Float Factory DPX2 EVOL w/ Gemini dual mode air spring system (Flow Mode - 150mm / Hustle Mode - 120mm, Remote Activated), Kashima coating, 3-Pos adj.
-
Rims
Stan's NoTubes Flow MK3, 32h, tubeless ready
-
Spokes
DT Swiss Competition, straight pull (Ai Offset dish - rear)
-
Tires
Maxxis Assegai, 29 x 2.5", 3C Compound, Max EXO puncture protection, tubeless ready
-
Pedals
Not Included
-
Crank
HollowGram, BB30 w/ X-Sync® SpideRing, 30T, Ai offset
-
Bottom Bracket
Cannondale Alloy PressFit30
-
Chain
Shimano XT, 12-speed
-
Rear Cogs
Shimano XT, 10-51, 12-speed
-
Rear Derailleur
Shimano XTR, Shadow Plus
-
Shifters
Shimano XT, 12-speed
-
Handlebar
Cannondale 1 Riser, Carbon, 15mm rise, 9° sweep, 4° rise, 780mm
-
Grips
Fabric Funguy Locking Grips
-
Stem
Cannondale 1, 3D Forged 6061 Alloy, 1-1/8", 31.8, 0°
-
Headset
Integrated, 1-1/8 to 1.5", sealed angular contact bearings
-
Brakes
Shimano XTR 4-piston hydro disc, 203/180mm RT900 rotors
-
Brake Levers
Shimano XTR Trail hydro disc
-
Saddle
Fabric Scoop Shallow Elite, cro-mo rails
-
Seatpost
Fox Factory Transfer Dropper, internal routing, 31.6, 100mm (S), 150mm (M-XL)
-
Speeds
12
-
Consumer Name 1
Jekyll
-
Consumer Name 2
Carbon 29 1
-
Fork Travel
(F) 150mm
-
Frame Details
150mm travel|Ai offset drivetrain|ISCG05|PF30-83|Flat mount brake|Tapered headtube
-
Frame Travel
(R) 150/120mm
-
Front Hub
DT 350 15x110
-
Front Tire Size
2.5
-
Material
Carbon/Aluminum
-
Rear Hub
DT 350 12x148 w/ Micro Spline
-
Tire Size
2.5
