FRAME
M5 alloy, Style-Specific DH Geometry, horst pivot flip chip for 27.5 or 29 rear wheel, BSA threaded BB, full internal cable routing with option for full external brake, 148mm rear spacing, sealed cartridge bearing pivots, replaceable derailleur hanger, 200mm of travel
SEAT BINDER
Alloy, 34.9mm
REAR SHOCK
RockShox Super Deluxe Ultimate DH Coil, external low speed compression, external rebound adjust, Trunnion mount, 225x75
FORK
RockShox BoXXer Ultimate 29, Charger 2.1 Damper, DH DebonAir spring, short crown, 20x110mm thru-axle, 56mm offset, 200mm of travel
STEM
Descendant 35mm Direct Mount Stem, 50mm length
HANDLEBARS
Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm, 35.0mm
GRIPS
Deity, Knuckleduster, Black
SADDLE
Body Geometry Henge DH, hollow titanium rails, 130mm
SEATPOST
Thomson, alloy, straight, 12-degree clamp
FRONT BRAKE
SRAM Code RSC, 4-piston caliper, hydraulic disc, 220mm
REAR BRAKE
SRAM Code RSC, 4-piston caliper, hydraulic disc, 200mm
REAR DERAILLEUR
SRAM X01 DH, 7-speed, trigger
SHIFT LEVERS
SRAM X01 DH, trigger, 7-speed
CASSETTE
SRAM X01 DH, 7-speed, 10-24t
CHAIN
Sram PC1130 w/ Powerlink, 11-speed
CHAINRINGS
34T
BOTTOM BRACKET
SRAM DUB, 83mm
CRANKSET
SRAM X01 DH, DUB, carbon, Direct mount ring, 165mm
RIMS
Roval Alloy DH, 29 front, 27.5 rear, 28mm internal width, 28h, tubeless ready
REAR HUB
DT Swiss 350, SRAM XD freehub, 6-bolt disc, high-low flange, sealed cartridge bearings, 12x148mm spacing, 28h
SPOKES
DT Swiss Competition, stainless steel, 14g
FRONT TIRE
Butcher BLCK DMND, 29x2.3"
REAR TIRE
Butcher BLCK DMND, 27.5x2.3"
INNER TUBES
Standard, Presta Valve
FRONT HUB
Alloy, sealed cartridge bearings, 20x110mm, 28h
